Xerox VersaLink B7025 Service Manual

April 2017
2-98
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-935B
Launch Issue
Status Indicator RAPs
012-935B Entrance Sensor RAP
BSD-ON: BSD 13.7 Office Finisher LX Transportation
Initial Actions
NOTE: Ensure the correct RAP is performed, refer to the 012-935 Entrance Sensor Entry RAP.
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Check for obstructions in the paper path
• Check that the finisher is docked correctly to ensure proper transport gate operation.
Procedure
Enter dC330 code 012-100. Actuate the transport entrance sensor, PL 13.35 Item 10. The
display changes.
YN
Check the wiring between J8868 pin 2 and P/J8988 pin 2 for an open or short circuit, or
a loose or damaged connector.
The wiring is good.
YN
Reconnect or repair as necessary.
Measure the voltage between P/J8988 pins 3 and 1 on the finisher PWB. The voltage is
approximately +5VDC.
YN
Install a new finisher PWB, PL 13.45 Item 2.
Measure the voltage between P/J8988 pin 2 on the finisher PWB and ground. Actuate the
finisher entrance sensor.
The voltage changes.
YN
Install a new transport entrance sensor, PL 13.35 Item 10
Install a new finisher PWB, PL 13.45 Item 2.
Install a new finisher PWB, PL 13.45 Item 2.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
