MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
A-26 Freescale Semiconductor
eTPU module configuration register ETPU_MCR 32-bit Base + 0x0000
eTPU coherent dual-parameter controller register ETPU_CDCR 32-bit Base + 0x0004
Reserved — — Base + (0x0008-0x000B)
eTPU miscellaneous compare register ETPU_MISCCMPR 32-bit Base + 0x000C
eTPU SCM off-range data register ETPU_SCMOFFDATAR 32-bit Base + 0x0010
eTPU A engine configuration register ETPU_ECR_A 32-bit Base + 0x0014
eTPU B engine Configuration register
2
ETPU_ECR_B
2
32-bit Base + 0x0018
Reserved — — Base + (0x001C-0x001F)
eTPU A time base configuration register ETPU_TBCR_A 32-bit Base + 0x0020
eTPU A time base 1 ETPU_TB1R_A 32-bit Base + 0x0024
eTPU A time base 2 ETPU_TB2R_A 32-bit Base + 0x0028
eTPU A STAC bus interface configuration register ETPU_REDCR_A 32-bit Base + 0x002C
Reserved — — Base + (0x0030-0x003F)
eTPU B time base configuration register
2
ETPU_TBCR_B
2
32-bit Base + 0x0040
eTPU B time base 1 ETPU_TB1R_B
2
32-bit Base + 0x0044
eTPU B time base 2 ETPU_TB2R_B
2
32-bit Base + 0x0048
eTPU B STAC bus interface configuration register
2
ETPU_REDCR_B
2
32-bit Base + 0x004C
Reserved — — Base + (0x0050-0x01FF)
eTPU A channel interrupt status register ETPU_CISR_A 32-bit Base + 0x0200
eTPU B channel interrupt status register
2
ETPU_CISR_B
2
32-bit Base + 0x0204
Reserved — — Base + (0x0208-0x020F)
eTPU A channel data transfer request status
register
ETPU_CDTRSR_A 32-bit Base + 0x0210
eTPU B channel data transfer request status
register
2
ETPU_CDTRSR_B
2
32-bit Base + 0x0214
Reserved — — Base + (0x0218-0x021F)
eTPU A channel interrupt overflow status register ETPU_CIOSR_A 32-bit Base + 0x0220
eTPU B channel interrupt overflow status register
2
ETPU_CIOSR_B
2
32-bit Base + 0x0224
Reserved — — Base + (0x0228-0x022F)
eTPU A channel data transfer request overflow
status register
ETPU_CDTROSR_A 32-bit Base + 0x0230
eTPU B channel data transfer request overflow
status register
2
ETPU_CDTROSR_B
2
32-bit Base + 0x0234
Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)
Register Description Register Name
Used
Size
Address Reference
