6.3.1.12.14 MPC5553: Pad Configuration Register 52 (SIU_PCR52)
The SIU_PCR52 register controls the pin function, direction, and static electrical attributes of the
DATA[24]_FEC_COL_CAL_DATA[8]_GPIO[52] pin.
Figure 6-27. MPC5553: DATA[24]_FEC_COL_CAL_DATA[8]_GPIO[52]
Pad Configuration Register (SIU_PCR52)
Refer to Table 6-16 for bit field definitions.
Address: Base + 0x00A8 Access: Read / write[3:11, 14:15]
0123456789101112131415
R 000
PA
1
1
CAL_DATA[8] is for calibration only.
OBE
2
2
When configured as DATA[24], FEC_COL, or CAL_DATA[8], the OBE bit has no effect. When configured as GPO, set the OBE
bit to 1.
IBE
3
3
When configured as DATA[24], FEC_COL, CAL_DATA[8], or GPO, set the IBE bit to 1 to reflect the pin state in the corresponding
GPDI register. Clear the IBE to 0 to reduce power consumption. When configured as GPI, set the IBE bit to 1.
DSC ODE
4
4
When configured as DATA[24] or CAL_DATA[8], clear the ODE bit to 0.
HYS
5
5
If external master operation is enabled, clear the HYS bit to 0.
00
WPE
6
6
Refer to the EBI section for weak pullup settings when configured as DATA[24] or CAL_DATA[8].
WPS
6
W
RESET: 000000001100001 1
Table 6-26. PCR52 PA Field Definition
PA Field Pin Function
0b000 GPIO[52]
0b001 DATA[24]
0b010 FEC_COL
0b011 Reserved
0b100 CAL_DATA[8]
1
1
For calibration only.
