System Interface Unit (SIU)
MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
Freescale Semiconductor 6-87
6.3.1.12.104 Pad Configuration Register 214 (SIU_PCR214)
The SIU_PCR214 register controls the enabling/disabling and drive strength of the ENGCLK pin. The
ENGCLK pin is enabled and disabled by setting and clearing the OBE bit. The ENGCLK pin is enabled
during reset.
Figure 6-116. ENGLCK Pad Configuration Register (SIU_PCR214)
Refer to Table 6-16 for bit field definitions.
6.3.1.12.105 Pad Configuration Register 215 (SIU_PCR215)
The SIU_PCR215 register controls the pin function, direction, and static electrical attributes of the
AN[12]_MA[0]_SDS pin.
Figure 6-117. AN[12]_MA[0]_SDS Pad Configuration Register (SIU_PCR215)
Refer to Table 6-16 for bit field definitions. The PA field for PCR215 is given in Table 6-41.
Address: Base + 0x01EC Access: Read / write[6, 8:9]
0123456789101112131415
R 000000
OBE
0
DSC
000000
W
RESET: 0000001011000000
Address: Base + 0x01EE Access: Read / write[4:5, 10, 12:13]
0123456789101112131415
R 0000
PA
1
1
Input and output buffers are enabled/disabled based on PA selection. The input and output buffers are disabled for the AN[12]
function. Only the output buffer is enabled for MA[0] and SDS
functions.
0000
ODE
0
SRC
00
W
RESET: 0000110000000000
Table 6-41. PCR215 PA Field Definition
PA Field Pin Function
0b00 SDS
0b01 Reserved
0b10 MA[0]
0b11 AN[12]
