System Interface Unit (SIU)
MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
6-88 Freescale Semiconductor
6.3.1.12.106 Pad Configuration Register 216 (SIU_PCR216)
The SIU_PCR216 register controls the pin function, direction, and static electrical attributes of the
AN[13]_MA[1]_SDO pin.
Figure 6-118. AN[13]_MA[1]_SDO Pad Configuration Register (SIU_PCR216)
Refer to Table 6-16 for bit field definitions. The PA field for PCR216 is given in Table 6-42.
6.3.1.12.107 Pad Configuration Register 217 (SIU_PCR217)
The SIU_PCR217 register controls the pin function, direction, and static electrical attributes of the
AN[14]_MA[2]_SDI pin.
Figure 6-119. AN[14]_MA[2]_SDI Pad Configuration Register (SIU_PCR217)
Refer to Table 6-16 for bit field definitions. The PA field for PCR217 is given in Table 6-43.
Address: Base + 0x01F0 Access: Read /write[4:5, 10, 12:13]
0123456789101112131415
R 0000
PA
1
1
Input and output buffers are enabled/disabled based on the PA selection. The input and output buffer is disabled for the AN[13]
function. Only the output buffer is enabled for the MA[1] and SDO functions.
0000
ODE
0
SRC
00
W
RESET: 0000110000000000
Table 6-42. PCR216 PA Field Definition
PA Field Pin Function
0b00 SDO
0b01 Reserved
0b10 MA[1]
0b11 AN[13]
Address: Base + 0x01F2 Access: Read / write[4:5, 10:15]
0123456789101112131415
R 0000
PA
1
1
Input and output buffers are enabled/disabled based on PA selection. The input and output buffer is disabled for the AN[14]
function. Only the output buffer is enabled for the MA[2] function; only the input buffer is enabled for the SDI function.
0000
ODE HYS SRC WPE
2
2
Clear the WPE bit to 0 when AN[14] or MA[2] are configured as the active signal; set the WPE bit to 1 when SDI is configured
as the active signal.
WPS
3
3
Set the WPS bit to 1 when SDI is configured as the active signal.
W
RESET: 000011000000000 0
