MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
Freescale Semiconductor 20-43
20.4.4.6.3 DSPI_C Connectivity (MPC5554 and MPC5553)
The DSPI_C connects to eTPU_A and SIU as shown in Figure 20-23.
Figure 20-23. DSPI_C Connectivity
Table 20-21 lists the DSPI_C connections.
11 eTPU_A Output Channel 26 11 eTPU_A Input Channel 26,
Input 1 on IMUX for External IRQ[11]
12 eTPU_A Output Channel 25 12 eTPU_A Input Channel 25,
Input 1 on IMUX for External IRQ[12]
13 eTPU_A Output Channel 24 13 eTPU_A Input Channel 24,
Input 1 on IMUX for External IRQ[13]
14 EMIOS Output Channel 13 14 EMIOS Input Channel 13,
Input 1 on IMUX for External IRQ[14]
15 EMIOS Output Channel 12 15 EMIOS Input Channel 12,
Input 1 on IMUX for External IRQ[15]
Table 20-21. DSPI_C Connectivity Table
DSPI_C IN[n] Connected to: DSPI_C OUT[n] Connected to:
0 eTPU_A Output Channel 12 0 Input 2 on IMUX for External IRQ[15]
1 eTPU_A Output Channel 13 1 Input 2 on IMUX for External IRQ[0]
2 eTPU_A Output Channel 14 2 Input 2 on IMUX for External IRQ[1]
3 eTPU_A Output Channel 15 3 Input 2 on IMUX for External IRQ[2]
4 eTPU_A Output Channel 0 4 Input 2 on IMUX for External IRQ[3]
5 eTPU_A Output Channel 1 5 Input 2 on IMUX for External IRQ[4]
6 eTPU_A Output Channel 2 6 Input 2 on IMUX for External IRQ[5]
7 eTPU_A Output Channel 3 7 Input 2 on IMUX for External IRQ[6]
8 eTPU_A Output Channel 4 8 Input 2 on IMUX for External IRQ[7]
9 eTPU_A Output Channel 5 9 Input 2 on IMUX for External IRQ[8]
10 eTPU_A Output Channel 6 10 Input 2 on IMUX for External IRQ[9]
11 eTPU_A Output Channel 7 11 Input 2 on IMUX for External IRQ[10]
Table 20-20. DSPI_B Connectivity Table (Continued)
DSPI_B IN[n] Connected to: DSPI_B OUT[n] Connected to:
SIU/IMUX
IN2 IRQ[0]
IN2 IRQ[14]
•
•
DSPI_C
OUT 1
OUT 15
eTPU_A
CH 12
CH 15
•
•
CH 0
CH 11
•
•
•
•
•
•
•
•
IN 0
IN 3
IN 4
IN 15
•
•
•
•
IN2 IRQ[15]OUT 0
•
•
