Lenze i550 - Page 559

Display code Short designaon Default seng Seng range Address Category
└ P108.02 Apparent power x.xxx kVA - (Read only) 0x2DA2:002 general
P109.xx Output energy
└ P109.01 Motor x.xx kWh - (Read only) 0x2DA3:001 general
└ P109.02 Generator x.xx kWh - (Read only) 0x2DA3:002 general
P110.xx AI1 diagnoscs
└ P110.01 AI1 terminal % x.x % - (Read only) 0x2DA4:001 general
└ P110.02 AI1 scaled freq. x.x Hz - (Read only) 0x2DA4:002 general
└ P110.03 AI1 scaled PID x.xx PID unit - (Read only) 0x2DA4:003 general
└ P110.04 AI1 scaled torq. x.x % - (Read only) 0x2DA4:004 general
└ P110.16 AI1 status - - (Read only) 0x2DA4:016 general
P111.xx AI2 diagnoscs
└ P111.01 AI2 terminal % x.x % - (Read only) 0x2DA5:001 general
└ P111.02 AI2 scaled freq. x.x Hz - (Read only) 0x2DA5:002 general
└ P111.03 AI2 scaled PID x.xx PID unit - (Read only) 0x2DA5:003 general
└ P111.04 AI2 scaled torq. x.x % - (Read only) 0x2DA5:004 general
└ P111.16 AI2 status - - (Read only) 0x2DA5:016 general
P112.xx AO1 diagnoscs
└ P112.01 AO1 Voltage x.xx V - (Read only) 0x2DAA:001 general
└ P112.02 AO1 Current x.xx mA - (Read only) 0x2DAA:002 general
P113.xx AO2 diagnoscs
└ P113.01 AO2 Current x.xx V - (Read only) 0x2DAB:001 Appl. I/O
└ P113.02 AO2 Voltage x.xx mA - (Read only) 0x2DAB:002 Appl. I/O
P114.xx DO actual freq.
└ P114.01 Digital output 1 x.x Hz - (Read only) 0x2646:001 general
P115.xx HTL inp. diag.
└ P115.01 Input frequency x.x Hz - (Read only) 0x2642:001 general
└ P115.02 Freq. setpoint x.x Hz - (Read only) 0x2642:002 general
└ P115.03 PID setpoint x.xx PID unit - (Read only) 0x2642:003 general
└ P115.04 Torque setpoint x.x % - (Read only) 0x2642:004 general
P116.00 Actual sw. freq. - - (Read only) 0x293A general
P117.xx Heatsink temp.
└ P117.01 Heatsink temp. x.x °C - (Read only) 0x2D84:001 general
P118.00 Digital inputs - - (Read only) 0x60FD general
P119.00 Keypad status - - (Read only) 0x2DAC general
P120.00 Int. HW states - - (Read only) 0x2DAD general
└ P121.01 PID setpoint x.xx PID unit - (Read only) 0x401F:001 general
└ P121.02 PID process var. x.xx PID unit - (Read only) 0x401F:002 general
└ P121.03 PID status - - (Read only) 0x401F:003 general
P123.00 Mot. i2t ulis. x % - (Read only) 0x2D4F general
P125.xx Inverter diag.
└ P125.01 Acve control - - (Read only) 0x282B:001 general
└ P125.02 Acve setpoint - - (Read only) 0x282B:002 general
└ P125.03 Keypad LCD stat. - - (Read only) 0x282B:003 general
└ P125.04 Drive mode - - (Read only) 0x282B:004 general
└ P125.05 Netw. contr.reg. - - (Read only) 0x282B:005 general
└ P125.06 Netw. setp.reg. - - (Read only) 0x282B:006 general
P126.xx Status words
└ P126.01 Cause of disable - - (Read only) 0x282A:001 general
└ P126.02 Cause of QSP - - (Read only) 0x282A:002 general
└ P126.03 Cause of stop - - (Read only) 0x282A:003 general
└ P126.05 Device status - - (Read only) 0x282A:005 general
P135.xx Device ulisat.
└ P135.04 ixt ulisaon x % - (Read only) 0x2D40:004 general
└ P135.05 Error response Fault [3] Selecon list 0x2D40:005 general
* Default seng depending on the size.
Using accessories
Keypad
Keypad parameterisaon mode
559
