Ruckus Wireless Virtual SmartZone - Softgre SNMP Mibs; Softgre Alarms and Events

This chapter lists the SNMP MIBs, alarms, and events that are related to SoftGRE.
SoftGRE SNMP MIBs
Table 48: OIDs related to SoftGRE on page 439 lists the SoftGRE related OIDs.
Table 48: OIDs related to SoftGRE
OIDNode NameParent Node
1.3.6.1.4.1.25053.1.3.2.1.1.2.3.1.1ruckusSCGWLANAPMacAddrruckusWLANAPInfo
1.3.6.1.4.1.25053.1.3.2.1.1.2.3.1.2ruckusSCGWLANAPSoftGREServer
1.3.6.1.4.1.25053.1.3.2.1.1.2.3.1.3ruckusSCGWLANAPSoftGREGWAddr
1.3.6.1.4.1.25053.1.3.2.1.1.2.3.1.4ruckusSCGWLANAPSoftGREActive
1.3.6.1.4.1.25053.1.3.2.1.1.2.3.1.5ruckusSCGWLANAPSoftGRETxPkts
1.3.6.1.4.1.25053.1.3.2.1.1.2.3.1.6ruckusSCGWLANAPSoftGRETxBytes
1.3.6.1.4.1.25053.1.3.2.1.1.2.3.1.7ruckusSCGWLANAPSoftGRERxPkts
1.3.6.1.4.1.25053.1.3.2.1.1.2.3.1.8ruckusSCGWLANAPSoftGRERxBytes
1.3.6.1.4.1.25053.1.3.2.1.1.2.3.1.9ruckusSCGWLANAPSoftGRETxPktsErr
1.3.6.1.4.1.25053.1.3.2.1.1.2.3.1.10ruckusSCGWLANAPSoftGRERxPktsErr
1.3.6.1.4.1.25053.1.3.2.1.1.2.3.1.11ruckusSCGWLANAPSoftGRETxPktsDropped
1.3.6.1.4.1.25053.1.3.2.1.1.2.3.1.12ruckusSCGWLANAPSoftGRERxPktsDropped
1.3.6.1.4.1.25053.1.3.2.1.1.2.3.1.13ruckusSCGWLANAPSoftGRETxPktsFrag
1.3.6.1.4.1.25053.1.3.2.1.1.2.3.1.14ruckusSCGWLANAPSoftGREICMPTotal
1.3.6.1.4.1.25053.1.3.2.1.1.2.3.1.15ruckusSCGWLANAPSoftGREICMPNoReply
1.3.6.1.4.1.25053.1.3.2.1.1.2.3.1.16ruckusSCGWLANAPSoftGREDisconnect
SoftGRE Alarms and Events
If there is no downstream traffic in the tunnel, APs that belong to the zone configured for SoftGRE
send out-of-band ICMP keep-alive messages (interval is configurable) to the active third party
WLAN gateway. If an AP does not receive a response from the active WLAN gateway, it triggers
an alarm and it automatically creates a SoftGRE tunnel to the standby WLAN gateway.
If the AP does not receive a response from the standby WLAN gateway either, the AP disconnects
all tunneled WLAN services. It continues to send keep-alive messages to both the active WLAN
gateway (primary GRE remote peer) and standby WLAN gateway (secondary GRE remote peer).
If it receives a response from either WLAN gateway, the AP restores all tunneled WLAN services
automatically.
There are four types of events that APs send to the controller:
• Failover from primary GRE remote peer to secondary GRE remote peer
