8
© 2011 - 2015 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C
ERROR CODE and TROUBLESHOOTING
8 - 71
[E0A0] Image transport ready time-out jam
[E550] Paper remaining on the transport path
LGC board
HDD
Classification Error item
Other paper jam Image data to be printed cannot be sent.
Check item Measures
Other • Remove the paper remained in front of the registration
sensor.
• If the error still occurs, check the following.
Power Check if the error is cleared by turning the power OFF and
then back ON.
SYS board • Connector check (SYS board -IMG board) (CN135)
• Board check
IMG board • Connector check (IMG board -SLG board) (IMG board -
LGC board) (CN422, CN423, CN424)
• Harness check
• Board check
LGC board • Connector check (CN319, CN320)
• Harness check
• Board check
HDD • Connector check
• HDD check
Replace parts Remarks
SYS board
IMG board
LGC board
HDD
Classification Error item
Other paper jam The paper is remaining on the transport path when printing is
finished (caused by a multiple paper feeding).
Step Check Item Result Measure
Next
Step
1
Jamming transport path Open the cover of the unit/area whose
picture is flashing on the control panel
and remove any paper on the transport
path.
2
Feed or transport roller possibly
causing multiple feeding
Check the feed roller.
3
Sensor in the jamming area • Sensor check (Refer to the table
below)
• Harness check
• Connector check
Replace parts Remarks
To Next Page
