e-STUDIO5540C/6540C/6550C/5560C/6560C/6570C © 2011 - 2015 TOSHIBA TEC CORPORATION All rights reserved
ERROR CODE and TROUBLESHOOTING
8 - 72
Relation between the jamming area and the corresponding sensors/covers.
4
PFC board • Harness check
• Connector check
• Board check
Notes:
If the jam is occurring in the ADU or LCF, check the board in each unit.
Replace parts Remarks
Feed or transport roller possibly
causing multiple feeding
Sensor in the jamming area Refer to the table below
PFC board
Jamming area Cover Sensor Test Mode/Input check
Paper path section Duplexing unit Registration sensor 03-[ALL]OFF/[4]/[B]
03-[COPY]ON/[5]/[H]
Transfer belt paper clinging
detection sensor
03-[ALL]OFF/[9]/[C]
2nd transfer side paper
clinging detection sensor
03-[ALL]OFF/[9]/[D]
1st drawer transport sensor 03-[SCAN]ON/[1]/[D]
Fuser Duplexing unit Fuser transport sensor 03-[ALL]OFF/[2]/[C]
03-[COPY]ON/[5]/[F]
Reverse path sensor 03-[ALL]OFF/[1]/[C]
03-[SCAN]ON/[3]/[E]
ADU Duplexing unit
Cover
Duplexing unit path exit sensor 03-[SCAN]ON/[3]/[G]
Duplexing unit path entrance
sensor
03-[SCAN]ON/[3]/[H]
Bypass unit Duplexing unit Bypass feed sensor 03-[SCAN]ON/[3]/[A]
Feeding area
(equipment)
Paper feed
cover
4th drawer transport sensor 03-[SCAN]ON/[1]/[A]
3rd drawer/tandem LCF
transport sensor
03-[SCAN]ON/[1]/[B]
2nd drawer transport sensor 03-[SCAN]ON/[1]/[C]
LCF LCF side cover Option LCF feed sensor 03-[SCAN]ON/[5]/[E]
Bridge unit Front cover Bridge unit path exit sensor 03-[ALL]OFF/[1]/[A]
03-[SCAN]ON/[3]/[C]
Bridge unit path entrance
sensor
03-[ALL]OFF/[1]/[B]
03-[SCAN]ON/[3]/[D]
Reverse sensor 03-[SCAN]ON/[3]/[F]
Reverse section stationary jam
detection sensor
03-[SCAN]ON/[4]/[A]
Upper exit section - Upper paper exit sensor 03-[ALL]OFF/[1]/[E]
03-[COPY]ON/[7]/[A]
Lower exit section - Lower paper exit sensor 03-[ALL]OFF/[4]/[C]
03-[COPY]ON/[5]/[G]
Reverse section Reverse path
cover
Reverse section paper
transport detection sensor
03-[COPY]ON/[8]/[F]
Finisher Finisher door Sensors in the finisher -
Step Check Item Result Measure
Next
Step
To Next Page
