194 CHAPTER 6: USING ROUTING PROTOCOL COMMANDS
Description
Use the display ospf lsdb command to view database information about the
OSPF connecting state.
Example
To display database information about the OSPF connecting state, enter the
following:
<SW5500>display ospf lsdb
OSPF Process 1 with Router ID 1.1.1.1
The information displays in the following format:
Link State Database
Area: 0.0.0.0
Type LinkState ID AdvRouter Age Len Sequence Metric Where
Rtr 2.2.2.2 2.2.2.2 465 36 8000000c 0 SpfTree
Rtr 1.1.1.1 1.1.1.1 449 36 80000004 0 SpfTree
Net 10.153.17.89 2.2.2.2 465 32 80000004 0 SpfTree
SNet 10.153.18.0 1.1.1.1 355 28 80000003 10 Inter List
Area: 0.0.0.1
Type LinkState ID AdvRouter Age Len Sequence Metric Where
Rtr 1.1.1.1 1.1.1.1 449 36 80000004 0 SpfTree
Rtr 3.3.3.3 3.3.3.3 429 36 8000000a 0 Clist
Net 10.153.18.89 3.3.3.3 429 32 80000003 0 SpfTree
SNet 10.153.17.0 1.1.1.1 355 28 80000003 10 Inter List
ASB 2.2.2.2 1.1.1.1 355 28 80000003 10 SumAsb List
AS External Database:
Type LinkState ID AdvRouter Age Len Sequence Metric Where
ASE 10.153.18.0 1.1.1.1 1006 36 80000002 1 Ase List
ASE 10.153.16.0 2.2.2.2 798 36 80000002 1 Uninitialized
ASE 10.153.17.0 2.2.2.2 623 36 80000003 1 Uninitialized
ASE 10.153.17.0 1.1.1.1 1188 36 80000002 1 Ase List
<SW5500> display ospf lsdb ase
OSPF Process 1 with Router ID 1.1.1.1
Link State Data Base
type: ASE
ls id: 2.2.0.0
adv rtr: 0.0.0.2
ls age: 349
len: 36
Tab le 31 Output Description of the display ospf lsdb Command
Field Description
Type Type of the LSA
LinkStateID Link state ID of the LSA
AdvRouter Router ID of the router originating the LSA
Age Age of the LSA
Len Length of the LSA
Sequence Sequence number of the LSA
Metric Cost from the router originating the LSA to LSA destination
Where Location of the LSA
