28 CHAPTER 1: USING SYSTEM ACCESS COMMANDS
This command without the summary parameter displays user interface type,
absolute/relative index, transmission speed, priority, authentication methods, and
physical location. This command with the
summary parameter displays one user
interface in use with user interface name and other user interface information.
Example
To display information on a user interface with an index number of 0, enter the
following.
<SW5500>display user-interface aux 0
The information is displayed in the following format:
Idx Type Tx/Rx Modem Privi Auth Int
0 AUX 0 19200 - 3 N -
+ : Current user-interface is active.
F : Current user-interface is active and work in async mode.
Idx : Absolute index of user-interface.
Type : Type and relative index of user-interface.
Privi: The privilege of user-interface.
Auth : The authentication mode of user-interface.
Int : The physical location of UIs.
A : Authentication use AAA.
N : Current UI need not authentication.
P : Authentication use current UI's password.
Display the summary information of user interface 0.
<SW5500>display user-interface 0 summary
0: U
1 character mode users. (U)
1 total UIs in use.
UI's name: aux0
Tab le 3 Output description of the display user-interface command
Field Description
+ Indicates that the user interface is in use
F Current user interface is in use and working in asynchronous
mode
Idx Displays the index number of the user interface
Type Displays the type and type number of the user interface
Tx/Rx Displays the user interface speed
Modem Displays the modem operation mode
Privi Indicates the command level that can be accessed from this
user interface
Auth Indicates the user interface authentication method
Int Indicates the physical location of the user interface
Tab le 4 Output Description of the display user-interface summary Command
Field Description
0: U User interface type
1 character mode users One type of user interface
