Fujitsu Oracle SPARC M12-2 User Manual

Table 4-16
Active/Cold Replacement Procedure of the CMU (continued)
Work
Order
Task Reference
3 Checking the logical domain assignment
status of memory resources mounted in
the SPARC M12-2S requiring maintenance
"3.2.4 Checking the Assignment Status
of Resources" in the Fujitsu SPARC M12
and Fujitsu M10/SPARC M10 Domain
Configuration Guide
4 Releasing I/O resources of the SPARC
M12-2S requiring maintenance from a
logical domain
"9.3 Releasing I/O Resources From a
Logical Domain"
5 Releasing the SPARC M12-2S requiring
maintenance from the physical partition
"9.4.3
Dynamically Releasing the
SPARC M12-2S From the Physical
Partition"
6 Releasing the SPARC M12-2S requiring
maintenance from the building block
configuration
"9.6.1 Releasing the SPARC M12-2S
From the Building Block Configuration"
7Placing the SPARC M12-2S requiring
maintenance into the cold state, and
removing the CMU from the SPARC
M12-2S
"17.4 Removing the
CMU or Memory"
8 Installing the CMU in the SPARC
M12-2S, and placing the SPARC M12-2S
that required maintenance into the hot
state
"17.5 Installing the CMU and Memory"
9 Incorporating the SPARC M12-2S that
required maintenance into the building
block configuration
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
10 Diagnosing the SPARC M12-2S with the
replacement CMU (*2)
"10.5.1 Diagnosing the SPARC M12
Hardware"
11 Diagnosing the XBU and crossbar cable
of the SPARC M12-2S with the
replacement CMU
"10.5.2 Diagnosing the XBU and
Crossbar Cable"
12 Confirming that there is no problem with
the replacement CMU
"10.5.3 Checking the FRU Status
After
Maintenance"
13 Incorporating the SPARC M12-2S that
required maintenance into the physical
partition
"10.6.1 Incorporating the SPARC
M12-2S Into the Physical Partition Using
PPAR DR"
14 Incorporating I/O resources of the SPARC
M12-2S requiring maintenance into a
logical domain (*1)
"10.7 Incorporating I/O Resources Into a
Logical Domain"
15 Checking the operating
condition of the
system and the I/O device usage status
"9.2 Checking the Operation Status and
Resource Usage Status of Oracle Solaris"
*1 If the replaced CMUL had the hardware RAID setting enabled, enable the setting again.
*2 If the replaced CMUU was in a SPARC M12-2S with no PCIe cards mounted, or if the CMUL was replaced, no
diagnosis is necessary (because diagnosis was performed in the previous step).
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 202388
