Table 4-20
Active/Cold Replacement Procedure of a PCI Expansion Unit (continued)
Work
Order
Task Reference
7Placing the SPARC M12-2S requiring
maintenance into the cold state
"9.8.2 Removing the Power Cords"
8Removing the FRUs in the faulty PCI
expansion unit
PCI Expansion Unit for Fujitsu SPARC
M12 and Fujitsu M10/SPARC M10 Service
Manual
9
Installing a FRU in the PCI expansion unit PCI Expansion Unit for Fujitsu SPARC
M12 and Fujitsu M10/SPARC M10 Service
Manual
10 Placing the SPARC M12-2S that required
maintenance into the hot state
"10.1.1 Installing a Power Cord"
11 Incorporating the SPARC M12-2S that
required maintenance into the building
block configuration
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
12 Diagnosing the SPARC M12-2S requiring
maintenance
"10.5.1 Diagnosing the SPARC M12
Hardware"
13 Confirming that there is no problem with
the replacement PCI expansion unit
"10.5.3 Checking the FRU Status After
Maintenance"
14 Incorporating the SPARC M12-2S that
required maintenance into the physical
partition (*1)
"10.6.1 Incorporating the SPARC
M12-2S Into the Physical
Partition Using
PPAR DR"
15 Incorporating I/O resources of the SPARC
M12-2S requiring maintenance into a
logical domain
"10.7 Incorporating I/O Resources Into a
Logical Domain"
16 Checking the operating condition of the
system and the I/O device usage status
"9.2 Checking the Operation Status and
Resource Usage Status of Oracle Solaris"
*1 Remove all the PCIe cards mounted in the PCI expansion unit when incorporating the SPARC M12-2S into the
physical partition.
4.2.14 Active/Cold Replacement Workflow of the XSCF
DUAL Control Cable
You can perform active/cold replacement of the XSCF DUAL control cable in the
following configuration:
■
Configuration connecting two or more SPARC M12-2S units to a physical partition
Table 4-21 shows the workflow for active/cold replacement of the XSCF DUAL
control cable.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 202394
