Table 5-3
Active/Hot Addition Procedure of a PCI Expansion Unit (continued)
Work
Order
Task Reference
4Removing the PCIe card filler from the
PCICS
"12.3.2 Removing a PCIe Card or PCIe
Card Filler"
5 Installing the link card in the PCICS "12.4.1 Installing a PCIe Card or PCIe
Card Filler"
6 Installing the link card in the SPARC
M12-2/M12-2S
"12.4.2 Incorporating a PCIe Card Into
the System"
7 Connecting a
PCI expansion unit to the
link card
"4.2 Connecting Cables to the PCI
Expansion Unit" in the Fujitsu SPARC
M12-2 Installation Guide
or
"5.2 Connecting Cables to the PCI
Expansion Unit" in the Fujitsu SPARC
M12-2S Installation Guide
8 Incorporating the added PCI expansion
unit into the system (*1)
"10.6.2 Incorporating an I/O Device
Into
the Physical Partition by Using the Hot
Plug Function"
9 Confirming that there is no problem with
the added PCI expansion unit
"10.5.3 Checking the FRU Status After
Maintenance"
10 Installing all the PCIe cards to be
mounted in the PCI expansion unit
"8.4 Installing a PCI Express Card" in
the PCI
Expansion Unit for Fujitsu SPARC
M12 and Fujitsu M10/SPARC M10 Service
Manual
11 Incorporating all the PCIe cards installed
in the PCI expansion unit into the system
"10.6.2 Incorporating an I/O Device Into
the Physical Partition by Using the Hot
Plug Function"
12 Confirming that there is no problem with
the added PCI
expansion unit
"10.5.3 Checking the FRU Status After
Maintenance"
13 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
14 Assigning the I/O resource to a logical
domain
"3.2 Operations and Commands Related
to Logical Domain Configurations" in the
Fujitsu SPARC M12 and Fujitsu
M10/SPARC M10 Domain Configuration
Guide
*1 The direct I/O function needs to be disabled. Do not mount any PCIe card in the PCI expansion unit during
active addition of the PCI expansion unit.
5.2 Active/Cold Addition Workflows
This section describes the workflows for active/cold addition of FRUs to the SPARC
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023154
