Table 4-41
Inactive/Cold Replacement Procedure of the Crossbar Cable (continued)
Work
Order
Task Reference
12 Switching the mode switch on the OPNL
to Locked, and powering on the physical
partition containing the SPARC M12-2S
that has undergone maintenance
"10.8 Powering on a Physical Partition"
13 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
Table 4-42
Inactive/Cold Replacement Procedure of the XBU
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the XBU to be replaced "8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2S that houses the XBU to be
replaced
"8.1.2 Checking Hardware"
4 Powering off the physical partition
containing the
SPARC M12-2S that
houses the XBU requiring maintenance
"9.5.1 Stopping a Specific Physical
Partition"
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
6 Releasing the SPARC M12-2S requiring
maintenance from the building block
configuration
"9.6.1 Releasing the SPARC M12-2S
From the Building Block Configuration"
7Placing the SPARC
M12-2S requiring
maintenance into the cold state, and
remo vi ng the XBU from the SPAR C M12-2S
"20.3 Removing an XBU"
8 Installing the XBU in the SPARC M12-2S,
and placing the SPARC M12-2S that
required maintenance into the hot state
"20.4 Installing an XBU"
9 Incorporating the SPARC M12-2S that
required maintenance into the building
block configuration
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
4.4.14 Inactive/Cold Replacement Workflow of the XBU
You can perform inactive/cold replacement of the XBU in the following configuration:
■
Building block configuration where two or more physical partitions are operating
Table 4-42 shows the workflow for inactive/cold replacement of the XBU.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023120
