Fujitsu Oracle SPARC M12-2 User Manual

Table 4-46
System-Stopped/Hot Replacement Procedure of the XSCFU
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the XSCFU to be replaced "8.2 Troubleshooting"
3 Confirming that the XSCFU to be
replaced is the standby or slave XSCF and
is currently replaceable (*1)
"Table 2-16 XSCFU LEDs and Their
States"
4 Stopping all physical partitions "9.5.2 Stopping All Physical Partitions"
4.5 System-Stopped/Hot Replacement
Workflows
This section describes the workflows for system-stopped/hot replacement of the
FRUs mounted in the SPARC M12.
Before performing replacement work, be sure to check the notes on maintenance
work in the Fujitsu SPARC M12 Product Notes of the XCP version used.
Each of the following sections puts together the order of work
and the tasks for each
FRU into a table. For details on each task, see the reference shown in the table.
The following FRUs are subject to system-stopped/hot replacement:
■
XSCFU
■
PCIe card
■
PSU
■
FANU
■
HDD/SSD
■
PCI expansion unit
4.5.1 System-Stopped/Hot Replacement Workflow of the
XSCFU
You can perform system-stopped/hot replacement of the XSCFU in the following
configuration:
■
Building block configuration connecting two or more SPARC M12-2S units
Before replacing the XSCFU, see "Precautions for XSCFU and PSUBP replacement" in
"7.1 Precautions for FRU Replacement."
Table 4-46 shows the workflow for system-stopped/hot replacement of the XSCFU.
Chapter 4 FRU Replacement Workflows 125
