Caution -
Insert the BPU slowly into the server. If a large vibration is applied, the
CMU may be damaged.
Figure 18-21
Installing the BPU
2.
Secure the BPU.
Tighten the four fixing screws shown in Figure 18-22 to secure the BPU.
Figure 18-22
Securing the BPU
18.5.3 Restoring the Server
This section describes the procedure for restoring the server after performing
maintenance on the BPU.
1.
Install the CMUL.
Insert the CMUL into the server, with the CMUL levers open. Then, tighten the
two fixing screws to secure the CMUL to the server. For details, see "17.5.2
Installing the CMU."
Chapter 18 Maintaining the Backplane Unit and PSU Backplane Unit 479
