Caution -
When loosening the fixing screws, be careful not to damage the PCIe cables
or radiator cores (heat exchanging parts) with the screwdriver, which may come into
contact with these components.
Figure 16-3
Removing the FANBPU
16.3.2 Removing the HDDBPU
This section describes the procedure for removing the HDDBPU.
1.
Loosen the three fixing screws of the HDDBPU.
Figure 16-4
Fixing Screws of the HDDBPU
