Table 5-20
System-Stopped/Hot Addition Procedure of the HDD/SSD
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Powering off all physical partitions "9.5.2 Stopping All Physical Partitions"
3 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
4Removing the filler unit from the SPARC
M12-2/M12-2S
"15.3.2 Removing
a Filler Unit"
5 Installing an HDD/SSD in the SPARC
M12-2/M12-2S
"15.4.1 Installing an HDD/SSD"
6 Diagnosing the SPARC M12-2/M12-2S
with the added HDD/SSD
"10.5.1 Diagnosing the SPARC M12
Hardware"
7 Confirming that there is no problem with
the added HDD/SSD
"10.5.3 Checking the FRU Status After
Maintenance"
8 Switching the mode switch on the
OPNL
to Locked
"2.3.2 OPNL Control Function"
9 Powering on all physical partitions "10.9.1 Starting the System With an
XSCF Command"
10 Assigning the I/O resource to a logical
domain
"3.2 Operations and Commands Related
to Logical Domain Configurations" in the
Fujitsu SPARC M12 and Fujitsu
M10/SPARC M10 Domain Configuration
Guide
Table 5-20 shows the workflow for system-stopped/hot addition of the HDD/SSD.
5.5.3 System-Stopped/Hot Addition Workflow of the PCI
Expansion Unit
Before adding the PCI expansion unit, mount it in the rack. (See "3.3 Mounting the
SPARC M12-2 and the PCI Expansion Unit in a Rack" in the Fujitsu SPARC M12-2
Installation Guide or "3.4 Mounting the SPARC M12-2S and the PCI Expansion Unit
in a Rack" in the Fujitsu SPARC M12-2S
Installation Guide.)
Table 5-21 shows the workflow for system-stopped/hot addition of a PCI expansion
unit.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023178
