Fujitsu Oracle SPARC M12-2 User Manual

XSCF>
showlogs error
Date: Feb 12 20:23:38 JST 2016
Code: 80000080-00b00000b7ff00b001-01a100270000000000000000
Status: Alarm Occurred: Feb 12 20:23:38.337 JST 2016
FRU: /BB#00/XSCFU,/BB#00/SCF_CBL#0
,/BB#01/XSCFU,*
Msg: XSCF data synchronization failed
22.3 Removing the XSCF BB Control Cable
This section describes the procedure for removing the XSCF BB control cable.
1.
Make a note of the XSCF BB control cable to be replaced.
Log in to the XSCF and execute the showstatus command or showlogs error
command. Then, make a note of the ports connected to the XSCF BB control
cable to be replaced. For details on the commands, see "8.2.2 Identifying a
Fault."
The underlined part in the error example below indicates that an error has been
found in the XSCF BB control cable connected to BB#00 and BB#01.
From the above error message and "Appendix A Lists of
Cable Connections in a
Building Block Configuration," identify the port number at the other end of the
connection of the target XSCF BB control cable.
In this example, "BB01-XSCF0" is the port number at the other end.
2.
Write the port number on labels.
The replacement XSCF BB control cable comes
with the labels shown in Figure
22-2. Write the connected port on these labels. For the XSCF BB control cable, use
LABEL-E. As in the example shown in Figure 22-2, write the connected port
number identified in step 1 on two labels.
Chapter 22 Maintaining the XSCF BB Control Cable 519
