Table 6-12
Inactive/Hot Removal Procedure of a PCI Expansion Unit (continued)
Work
Order
Task Reference
4 Confirming that you can release the PCI
expansion unit to be removed (*1)
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
5Saving logical domain configuration
information
"9.1.1 Saving Logical Domain
Configuration Information"
6 Powering off the physical partition
containing the SPARC M12-2S from
which to remove the PCI expansion
unit
"9.5.1 Stopping a Specific Physical
Partition"
7 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
8 Releasing the PCI expansion unit to be
removed and the link card
PCI Expansion Unit for Fujitsu SPARC
M12 and Fujitsu M10/SPARC M10 Service
Manual
9Removing the PCICS that houses the
link
card, from the SPARC M12-2S
"12.3.1 Enabling the Removal of a PCIe
Card"
10 Removing the link card from the PCICS "12.3.2 Removing a PCIe Card or PCIe
Card Filler"
11 Installing a PCIe card filler in the PCICS,
and installing the PCICS in the SPARC
M12-2S
"12.4.1 Installing a PCIe Card
or PCIe
Card Filler"
12 Powering on the physical partition
containing the SPARC M12-2S that
underwent maintenance
"10.9.1 Starting the System With an
XSCF Command"
13 Confirming that there is no problem with
the system from which the PCI expansion
unit was removed
"10.5.3 Checking the FRU Status After
Maintenance"
14 Switching the mode
switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
15 Checking the operating condition of the
system (*1)
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
16 Saving logical domain configuration
information
"9.1.1 Saving Logical Domain
Configuration Information"
*1 Reassign I/O resources to logical domains as required. For details, see "3.2.18 Configuring an I/O Device" in
the Fujitsu SPARC M12 and Fujitsu M10/SPARC M10 Domain Configuration Guide.
6.4 Inactive/Cold Removal Workflows
This section describes the workflows for inactive/cold removal of the FRUs mounted
in the SPARC M12-2S, and the workflow for inactive/cold removal of the SPARC
M12-2S.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023206
