Fujitsu Oracle SPARC M12-2 User Manual

Location
No.
Unit
1 Front cover
2FANU
3FANBPU
4 HDDBPU
5 HDD/SSD
6OPNL (*1)
*1 The OPNL is installed in the HDDBPU.
Caution -
Before you handle any unit, be sure to wear a wrist strap to ground any
static electricity. If you perform this procedure without a wrist strap, individual
components or the overall system may be seriously damaged. For details, see "1.5
Precautions on Static Electricity."
16.2 Before Maintenance on the HDDBPU
and OPNL
When replacing the HDDBPU, perform one of the maintenance procedures listed
below.
- 4.2.7 Active/Cold Replacement Workflow of the HDDBPU
- 4.4.7 Inactive/Cold Replacement Workflow of the HDDBPU
- 4.6.7 System-Stopped/Cold Replacement Workflow of the HDDBPU
When replacing the OPNL, perform one of the maintenance procedures listed below.
- 4.2.8 Active/Cold Replacement
Workflow of the OPNL
- 4.4.8 Inactive/Cold Replacement Workflow of the OPNL
- 4.6.8 System-Stopped/Cold Replacement Workflow of the OPNL
16.3 Removing the HDDBPU or OPNL
This section describes the procedure for removing the HDDBPU or OPNL.
16.3.1 Enabling the Removal of the HDDBPU or OPNL
Before removing the HDDBPU or OPNL, you need to remove the FANUs and
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023422
