Table 4-1
Active/Hot Replacement Procedure of the XSCFU
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the XSCFU to be replaced "8.2 Troubleshooting"
3 Confirming that the XSCFU to be
replaced is the standby or slave XSCF and
is currently replaceable (*1)
"Table 2-16 XSCFU LEDs and Their
States"
4 Releasing the XSCFU from the SPARC
M12-2S
"9.6.4 Releasing the XSCFU"
5Removing the XSCFU from the SPARC
M12-2S
"11.4 Removing the XSCFU"
6 Switching the SD card (*2) "11.5 Switching an SD Card"
7
Mounting the XSCFU in the SPAR C M12-2S "11.6 Installing the XSCFU"
8 Incorporating the XSCFU into the SPARC
M12-2S
"10.4.4 Incorporating the XSCFU"
9 Confirming that there is no problem with
the replacement XSCFU
"10.5.3 Checking the FRU Status After
Maintenance"
10 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
*1 Before replacing the XSCFU, confirm that the READY LED of the XSCFU is lit in green or off.
If the READY LED of the XSCFU is blinking, wait until the LED stays lit or is turned off.
*2 If the SD card installed in the maintenance part will be used,
this work is not required.
■
PSU
■
FANU
■
HDD/SSD
■
PCI expansion unit
4.1.1 Active/Hot Replacement Workflow of the XSCFU
You can perform active/hot replacement of the XSCFU in the following configuration:
■
Building block configuration connecting two or more SPARC M12-2S units
Before replacing the XSCFU, see "Precautions for XSCFU and PSUBP replacement" in
"7.1 Precautions for FRU Replacement."
Table 4-1 shows the workflow for active/hot replacement of the XSCFU.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 202370
