Fujitsu Oracle SPARC M12-2 User Manual

Table 4-53
System-Stopped/Cold Replacement Procedure of a PCIe Card (continued)
Work
Order
Task Reference
6Removing the power cords of all the
SPARC M12-2/M12-2S units
"9.8.2 Removing the Power Cords"
7Removing the faulty PCIe card from the
SPARC M12-2/M12-2S
"12.3.1 Enabling the Removal of a PCIe
Card"
8Removing the faulty PCIe card from the
PCICS
"12.3.2 Removing a PCIe Card or PCIe
Card Filler"
9 Installing the
replacement PCIe card in
the PCICS to install it in the SPARC
M12-2/M12-2S or PCI expansion unit
"12.4.1 Installing a PCIe Card or PCIe
Card Filler"
10 Installing the power cords on all the
SPARC M12-2/M12-2S units
"10.1.1 Installing a Power Cord"
11 Diagnosing all the SPARC M12-2/M12-2S
units
"10.5.1 Diagnosing the
SPARC M12
Hardware"
12 Confirming that there is no problem with
the replacement PCIe card
"10.5.3 Checking the FRU Status After
Maintenance"
13 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
14 Powering on the physical partitions "10.9.1 Starting the System With an
XSCF Command"
15 Checking the operating condition
of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
Table 4-54
System-Stopped/Cold Replacement Procedure of the PSU
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Checking the PSU of the SPARC M12-2/
M12-2S
"8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2/M12-2S that houses the
PSU to be replaced
"Table 2-20 PSU LEDs and Their States"
4.6.3 System-Stopped/Cold Replacement Workflow of
the PSU
Before replacing the PSU, see "Precautions for PSU replacement" in "7.1 Precautions
for FRU Replacement."
Table 4-54 shows the workflow for system-stopped/cold replacement of the PSU.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023134
