Fujitsu Oracle SPARC M12-2 User Manual

Table 4-4
Active/Hot Replacement Procedure of the FANU
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Releasing the faulty FANU from the
system
"9.6.2 Releasing the FANU"
3Removing the FANU from the SPARC
M12-2/M12-2S
"14.3.1 Removing a FANU"
4 Installing the FANU in the SPARC
M12-2/M12-2S
"14.4.2 Installing a FANU
"
5 Incorporating the FANU into the system "10.4.2 Incorporating the FANU"
6 Confirming that there is no problem with
the replacement FANU
"10.5.3 Checking the FRU Status After
Maintenance"
Table 4-5
Active/Hot Replacement Procedure of the HDD/SSD
Work
Order
Task Reference
1 Checking the operating condition of the
system and the I/O device usage status
"9.2 Checking the Operation Status and
Resource Usage Status of Oracle Solaris"
2 Releasing the faulty HDD/SSD from the
system
"9.4.2 Dynamically Releasing the
HDD/SSD From a Logical Domain"
3Removing the HDD/SSD from the
SPARC M12-2/M12-2S
"15.3.1 Removing an
HDD/SSD"
4 Installing an HDD/SSD in the SPARC
M12-2/M12-2S
"15.4.1 Installing an HDD/SSD"
5 Incorporating the replacement HDD/SSD
into the system
"10.6.2 Incorporating an I/O Device Into
the Physical Partition by Using the Hot
Plug Function"
6 Confirming that there is no problem with
the replacement HDD/SSD
"10.5.3 Checking the FRU Status After
Maintenance"
4.1.5 Active/Hot Replacement Workflow of the HDD/SSD
If the HDD/SSD to be replaced has a mirror volume configuration, see "Active/Hot
Replacement Workflow of the HDD/SSD With a Mirror Volume Configuration."
Before replacing the HDD/SSD, see "Precautions for HDD/SSD replacement" in "7.1
Precautions for FRU Replacement."
Table 4-5 shows the workflow for active/hot replacement of the HDD/SSD.
Chapter 4 FRU Replacement Workflows 73
