Fujitsu Oracle SPARC M12-2 User Manual

Note -
The XSCF DUAL control cable is used in a building block configuration consisting of
multiple SPARC M12-2S units.
Chapter 21
Maintaining the XSCF DUAL Control
Cable
This chapter describes the maintenance procedures for the XSCF DUAL control cable.
■
XSCF DUAL Control Port
■
Before Maintenance on the XSCF DUAL Control Cable
■
Removing the XSCF DUAL Control Cable
■
Installing the XSCF DUAL Control Cable
21.1 XSCF DUAL Control Port
The XSCF DUAL control cable is used to connect a SPARC M12-2S that houses the
master XSCF or a crossbar box to a SPARC M12-2S that houses the standby XSCF or a
crossbar box.
Connect the XSCF DUAL control cable to the XSCF DUAL control port on the rear of
the
SPARC M12-2S or crossbar box. Figure 21-1 shows the location of the XSCF
DUAL control port.
509
