Fujitsu Oracle SPARC M12-2 User Manual

Table 4-49
System-Stopped/Hot Replacement Procedure of the FANU (continued)
Work
Order
Task Reference
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
6 Releasing the FANU from the SPARC
M12-2/M12-2S
"9.6.2 Releasing the FANU"
7Removing the FANU from the SPARC
M12-2/M12-2S
"14.3.1 Removing a FANU"
8 Installing the FANU in the SPARC
M12-2/M12-2S
"14.4.2 Installing a FANU"
9 Incorporating the FANU into the
SPARC
M12-2/M12-2S
"10.4.2 Incorporating the FANU"
10 Confirming that there is no problem with
the replacement FANU
"10.5.3 Checking the FRU Status After
Maintenance"
11 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
12 Powering on the physical partitions "10.9.1 Starting the System With an
XSCF Command"
13 Checking the
operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
Table 4-50
System-Stopped/Hot Replacement Procedure of the HDD/SSD
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the HDD/SSD to be replaced "8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2/M12-2S that houses the
HDD/SSD to be replaced
"Table 2-22 HDD/SSD LEDs and Their
States"
4 Stopping all physical
partitions "9.5.2 Stopping All Physical Partitions"
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
4.5.5 System-Stopped/Hot Replacement Workflow of the
HDD/SSD
Before replacing the HDD/SSD, see "Precautions for HDD/SSD replacement" in "7.1
Precautions for FRU Replacement."
Table 4-50 shows the workflow for system-stopped/hot replacement of the HDD/SSD.
Chapter 4 FRU Replacement Workflows 129
