Fujitsu Oracle SPARC M12-2 User Manual

Table 4-23
Inactive/Hot Replacement Procedure of the XSCFU
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the XSCFU to be replaced "8.2 Troubleshooting"
3 Confirming that the XSCFU to be
replaced is the standby or slave XSCF and
is currently replaceable (*1)
"Table 2-16 XSCFU LEDs and Their
States"
4 Powering off the physical partition
containing the SPARC M12-2S that
houses the FRU requiring maintenance
"9.5.1 Stopping a Specific Physical
Partition"
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
6 Releasing the XSCFU from the SPARC
M12-2S
"9.6.4 Releasing the XSCFU"
7Removing the XSCFU from the SPARC
M12-2S
"11.4 Removing the XSCFU"
8 Switching the SD card (*2) "11.5 Switching an SD Card"
9
Installing the XSCFU in the SPARC M12-2S "11.6 Installing the XSCFU"
10 Incorporating the XSCFU into the SPARC
M12-2S
"10.4.4 Incorporating the XSCFU"
11 Confirming that there is no problem with
the replacement XSCFU
"10.5.3 Checking the FRU Status After
Maintenance"
12 Switching the mode switch on the OPNL
to Locked, and powering on the physical
partition containing the SPARC
M12-2S
that has undergone maintenance
"10.8 Powering on a Physical Partition"
13 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
*1 Before replacing the XSCFU, confirm that the READY LED of the XSCFU is lit in green or off. If the READY
LED of the XSCFU is blinking, wait until the LED stays lit or is turned off.
- If the XSCFU requiring replacement is not running when the physical partition
containing the XSCFU is
powered on, perform active/hot replacement.
- If the physical partition containing the XSCFU requiring replacement is powered off, you can perform hot
replacement of the XSCFU even when it is not running. In that case, proceed to step 5.
*2 If the SD card installed in the
maintenance part will be used, this work is not required.
4.3.2 Inactive/Hot Replacement Workflow of a PCIe Card
You can perform inactive/hot replacement of a PCIe card in the following configuration:
■
Building block configuration where two or more physical partitions are operating
Before replacing the PCIe card, see "Precautions for PCIe card replacement" in "7.1
Precautions for FRU Replacement."
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 202398
