Table 6-24
System-Stopped/Cold Removal Procedure of the CMUU
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Releasing the assignment of the CPU and
memory resources of the CMUU to be
removed
"Chapter 3 Operations for Domain
Configuration" in the Fujitsu SPARC M12
and Fujitsu M10/SPARC M10 Domain
Configuration Guide
3 Confirming
that you can remove the
CMUU to be removed (*1)
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
4Saving logical domain configuration
information
"9.1.1 Saving Logical Domain
Configuration Information"
5 Powering off all physical partitions "9.5.2 Stopping All Physical Partitions"
6 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
7Removing the power cords of all the
SPARC M12-2/M12-2S units
"9.8.2 Removing the Power Cords"
8 Enabling the removal of the CMUU "17.4.1 Enabling the Removal of the
CMU"
9Removing the CMUU from the SPARC
M12-2/M12-2S
"17.4.2 Removing the CMU"
10 Installing the filler unit in the SPARC
M12-2/M12-2S
"17.5.2 Installing the CMU"
11 Assembling the SPARC M12-2/M12-2S
from which the CMUU was removed
"17.5.3 Restoring the Server"
12 Installing the power cords of all the
SPARC M12-2/M12-2S units
"10.1.1 Installing a Power Cord"
13 Diagnosing all the SPARC M12-2/M12-2S
units
"10.5.1 Diagnosing the SPARC M12
Hardware"
14 Confirming that there is no
problem with
the system from which the CMUU was
removed
"10.5.3 Checking the FRU Status After
Maintenance"
6.6.3 System-Stopped/Cold Removal Workflow of the
CMUU
Before removing the CMUU, see "Precautions for CMUU removal" in "7.3
Precautions for FRU Reduction."
Table 6-24 shows the workflow for system-stopped/cold removal of the CMUU.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023222
