Note -
XBUs are used in the SPARC M12-2S.
(1) (2)
Chapter 20
Maintaining the Crossbar Unit
This chapter describes the maintenance procedures for XBUs.
■
Locations of the XBU
■
Before Maintenance on an XBU
■
Removing an XBU
■
Installing an XBU
20.1 Locations of the XBU
Two XBUs are mounted in the SPARC M12-2/M12-2S.
Figure 20-1 shows the mounting locations of the XBUs.
Figure 20-1
Locations of the XBU
