Table 6-10
Inactive/Hot Removal Procedure of a PCIe Card
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Checking the usage status of the PCIe
card to be removed
"9.2.2 Checking the Assignment Status
of I/O Devices"
3 Releasing the I/O resources assigned to
the PCIe card to be removed
"9.3 Releasing
I/O Resources From a
Logical Domain"
4 Confirming that you can release the PCIe
card to be removed
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
5Saving logical domain configuration
information
"9.1.1 Saving Logical Domain
Configuration Information"
6 Powering off the physical partition
containing the SPARC M12-2S from
which
to remove the PCIe card
"9.5.1 Stopping a Specific Physical
Partition"
7 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
8Removing the PCICS in which the PCIe
card to be removed is mounted from the
SPARC M12-2S
"12.3.1 Enabling the Removal of a PCIe
Card"
9Removing the
PCIe card to be removed,
from the PCICS
"12.3.2 Removing a PCIe Card or PCIe
Card Filler"
10 Installing a PCIe card filler in the PCICS,
and installing the PCICS in the SPARC
M12-2S
"12.4.1 Installing a PCIe Card or PCIe
Card Filler"
Each of the following sections puts together the order of work and the tasks for each
FRU into a table. For details on each task, see the reference shown in the table.
The following FRUs are subject to inactive/hot removal:
■
PCIe card
■
HDD/SSD
■
PCI expansion unit
6.3.1 Inactive/Hot Removal Workflow of a PCIe Card
You can perform inactive/hot removal of a PCIe card in the following configuration:
■
Building block configuration where two or more physical partitions are operating
Before removing a PCIe card, see "Precautions for PCIe card removal" in "7.3
Precautions for FRU Reduction."
Table 6-10 shows the workflow for inactive/hot removal of a PCIe card.
Chapter 6 FRU Removal Workflows 203
