Fujitsu Oracle SPARC M12-2

Table 4-32
Inactive/Cold Replacement Procedure of the FANU (continued)
Work
Order
Task Reference
7Placing the SPARC M12-2S requiring
maintenance into the cold state
"9.8.2 Removing the Power Cords"
8Removing the FANU from the SPARC
M12-2S
"14.3.1 Removing a FANU"
9
Installing the FANU in the SPARC M12-2S,
and placing the SPARC M12-2S that
required maintenance into the hot state
"14.4.2 Installing a FANU"
10 Incorporating the SPARC M12-2S that
required maintenance into the building
block configuration
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
11 Confirming that there is no problem with
the replacement FANU
"10.5.3 Checking
the FRU Status After
Maintenance"
12 Switching the mode switch on the OPNL
to Locked, and powering on the physical
partition containing the SPARC M12-2S
that has undergone maintenance
"10.8 Powering on a Physical Partition"
13 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical
Domains"
Table 4-33
Inactive/Cold Replacement Procedure of the FANBPU
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the FANBPU to be replaced "8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2S that houses the FANBPU
to be replaced
"8.1.2 Checking Hardware"
4.4.5 Inactive/Cold Replacement Workflow of the
FANBPU
You can perform inactive/cold replacement of the FANBPU in the following
configuration:
■
Building block configuration where two or more physical partitions are operating
Before replacing the FANBPU, see "Precautions for FANBPU replacement" in "7.1
Precautions for FRU Replacement."
Table 4-33 shows the workflow for inactive/cold replacement of the FANBPU.
Chapter 4 FRU Replacement Workflows 109
