Table 5-6
Active/Cold Addition Procedure of the CMUU (continued)
Work
Order
Task Reference
9 Installing the CMUU in the SPARC
M12-2S (*1)
"17.5 Installing the CMU and Memory"
10 Installing the power cords on the SPARC
M12-2S with the added CMUU, and
incorporating it into the building block
configuration
"10.1.1 Installing a Power Cord"
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
11 Diagnosing
the SPARC M12-2S requiring
maintenance (*2)
"10.5.1 Diagnosing the SPARC M12
Hardware"
12 Diagnosing the XBU and crossbar cable
of the SPARC M12-2S requiring
maintenance
"10.5.2 Diagnosing the XBU and
Crossbar Cable"
13 Confirming that there is no problem with
the added CMUU
"10.5.3 Checking the FRU Status After
Maintenance"
14 Incorporating the SPARC
M12-2S into the
physical partition
"10.6.1 Incorporating the SPARC
M12-2S Into the Physical Partition Using
PPAR DR"
15 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
16 Assigning the resources of the added
SPARC M12-2S to logical domains
"3.2 Operations and Commands Related
to Logical Domain Configurations" in
the
Fujitsu SPARC M12 and Fujitsu
M10/SPARC M10 Domain Configuration
Guide
*1 If the CMUU has no memory installed, install memory before installing the CMUU in the SPARC M12-2S.
*2 If the CMU was added to a SPARC M12-2S with no PCIe cards mounted, no diagnosis is necessary (because
diagnosis was performed in the previous step).
5.2.4 Active/Cold Addition Workflow of Memory
You can perform active/cold addition of memory in the following configuration:
■
Configuration connecting two or more SPARC M12-2S units to a physical partition
Before adding memory, see "Precautions for memory expansion" in "7.2 Precautions
for FRU Expansion."
Table 5-7 shows the workflow for active/cold addition of memory.
Chapter 5 FRU Addition Workflows 159
