Table 5-7
Active/Cold Addition Procedure of Memory
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Checking the logical domain assignment
status of CPU resources mounted in the
SPARC M12-2S requiring maintenance
"3.2.4 Checking the Assignment Status
of Resources" in the Fujitsu SPARC M12
and Fujitsu M10/SPARC M10 Domain
Configuration Guide
3 Checking the logical domain assignment
status of memory resources mounted in
the SPARC M12-2S requiring maintenance
"3.2.4 Checking the Assignment Status
of Resources" in the Fujitsu SPARC M12
and Fujitsu M10/SPARC M10 Domain
Configuration Guide
4 Releasing the logical domain assignment
of PCIe cards mounted in the SPARC
M12-2S requiring maintenance
"9.3 Releasing I/O Resources From a
Logical Domain"
5 Releasing the SPARC M12-2S requiring
maintenance from the physical
partition
"9.4.3 Dynamically Releasing the
SPARC M12-2S From the Physical
Partition"
6 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
7 Releasing the SPARC M12-2S requiring
maintenance from the building block
configuration, and removing the power
cords
"9.6.1 Releasing the SPARC M12-2S
From the Building Block Configuration"
"
9.8.2 Removing the Power Cords"
8Removing the CMU from the SPARC
M12-2S
"17.4 Removing the CMU or Memory"
9 Installing memory in the CMU and
installing this unit in the SPARC M12-2S
"17.5 Installing the CMU and Memory"
10 Installing the power cords on the SPARC
M12-2S requiring maintenance, and
incorporating it into
the building block
configuration
"10.1.1 Installing a Power Cord"
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
11 Diagnosing the SPARC M12-2S requiring
maintenance (*1)
"10.5.1 Diagnosing the SPARC M12
Hardware"
12 Diagnosing the XBU and crossbar cable
of the SPARC M12-2S requiring
maintenance
"10.5.2 Diagnosing the XBU and
Crossbar
Cable"
13 Confirming that there is no problem with
the added memory
"10.5.3 Checking the FRU Status After
Maintenance"
14 Incorporating the SPARC M12-2S into the
physical partition
"10.6.1 Incorporating the SPARC
M12-2S Into the Physical Partition Using
PPAR DR"
15 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control
Function"
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023160
