Table 6-16
Inactive/Cold Removal Procedure of Memory (continued)
Work
Order
Task Reference
10 Removing the memory from the CMU (*1) "17.4.3 Removing Memory"
11 Installing the CMU from which the
memory was removed, in the SPARC
M12-2S
"17.5.2 Installing the CMU"
12 Assembling the SPARC M12-2S from
which the memory was removed
"17.5.3 Restoring the Server"
13 Incorporating the SPARC M12-2S from
which the memory was removed into the
building block configuration
"10.4.1
Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
14 Diagnosing the SPARC M12-2S from
which the memory was removed (*2)
"10.5.1 Diagnosing the SPARC M12
Hardware"
15 Diagnosing the XBU and crossbar cable,
in the building block configuration, of the
SPARC M12-2S from which the memory
was removed
"10.5.2 Diagnosing the XBU
and
Crossbar Cable"
16 Confirming that there is no problem with
the SPARC M12-2S after the removal of
the memory
"10.5.3 Checking the FRU Status After
Maintenance"
17 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
18 Powering on the physical partition
containing the SPARC M12-2S that
underwent
maintenance
"10.9.1 Starting the System With an
XSCF Command"
19 Checking the operating condition of the
physical partition and logical domains (*3)
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
20 Saving logical domain configuration
information
"9.1.1 Saving Logical Domain
Configuration Information"
*1 Observe the installation rules to remove memory. For details, see "2.2 Checking the Memory Configuration
Rules."
*2 If the memory was removed from a SPARC M12-2S with no PCIe cards mounted, no diagnosis is necessary
(because diagnosis was performed in the previous step).
*3 Reconfigure logical domains as required. For details,
see "Chapter 3 Operations for Domain Configuration" in
the Fujitsu SPARC M12 and Fujitsu M10/SPARC M10 Domain Configuration Guide.
6.4.5 Inactive/Cold Removal Workflow of the PCI
Expansion Unit
You can perform inactive/cold removal of a PCI expansion unit in the following
configuration:
■
Building block configuration where two or more physical partitions are operating
Table 6-17 shows the workflow for inactive/cold removal of a PCI expansion unit.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023212
