Table 5-19
System-Stopped/Hot Addition Procedure of a PCIe Card
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Powering off all physical partitions "9.5.2 Stopping All Physical Partitions"
3 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
4Removing the PCICS from the SPARC
M12-2/M12-2S
"12.3.1 Enabling the
Removal of a PCIe
Card"
5
Removing the PCIe card filler of the PCICS "12.3.2 Removing a PCIe Card or PCIe
Card Filler"
6 Installing a PCIe card in the PCICS to
install it in the SPARC M12-2/M12-2S
"12.4.1 Installing a PCIe Card or PCIe
Card Filler"
7 Diagnosing the SPARC M12-2/M12-2S
with the added PCIe card
"10.5.1 Diagnosing the SPARC M12
Hardware"
8 Confirming that there
is no problem with
the added PCIe card
"10.5.3 Checking the FRU Status After
Maintenance"
9 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
10 Powering on all physical partitions "10.9.1 Starting the System With an
XSCF Command"
11 Assigning the I/O resource to a logical
domain
"3.2 Operations and
Commands Related
to Logical Domain Configurations" in the
Fujitsu SPARC M12 and Fujitsu
M10/SPARC M10 Domain Configuration
Guide
5.5.1 System-Stopped/Hot Addition Workflow of a PCIe
Card
Before adding the PCIe card, see "Precautions for PCIe card addition" in "7.2
Precautions for FRU Expansion."
Table 5-19 shows the workflow for system-stopped/hot addition of a PCIe card.
5.5.2 System-Stopped/Hot Addition Workflow of the
HDD/SSD
Before adding the HDD/SSD, see "Precautions for HDD/SSD addition" in "7.2
Precautions for FRU Expansion."
Chapter 5 FRU Addition Workflows 177
