Table 5-1
Active/Hot Addition Procedure of a PCIe Card
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
3Removing the PCICS from the SPARC
M12-2/M12-2S or PCI expansion unit
"12.3.1 Enabling the Removal of a PCIe
Card"
4
Removing the PCIe card filler of the PCICS "12.3.2 Removing a PCIe Card or PCIe
Card Filler"
5 Installing a PCIe card in the PCICS to
install it in the SPARC M12-2/M12-2S or
PCI expansion unit
"12.4.1 Installing a PCIe Card or PCIe
Card Filler"
6 Incorporating the added PCIe card into
the system
"10.6.2 Incorporating an I/O Device Into
the Physical Partition by Using the Hot
Plug Function"
7 Confirming that there is no problem with
the added PCIe card
"10.5.3 Checking the FRU Status After
Maintenance"
8 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
9 Assigning the I/O resource to a logical
domain
"3.2 Operations and
Commands Related
to Logical Domain Configurations" in the
Fujitsu SPARC M12 and Fujitsu
M10/SPARC M10 Domain Configuration
Guide
5.1.1 Active/Hot Addition Workflow of a PCIe Card
Before adding the PCIe card, see "Precautions for PCIe card addition" in "7.2
Precautions for FRU Expansion."
Table 5-1 shows the workflow for active/hot addition of a PCIe card using the PCI
Hot Plug function.
5.1.2 Active/Hot Addition Workflow of the HDD/SSD
Before adding the HDD/SSD, see "Precautions for HDD/SSD addition" in "7.2
Precautions for FRU Expansion."
Table 5-2 shows the workflow for active/hot addition of the HDD/SSD.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023152
