Fujitsu Oracle SPARC M12-2 User Manual

Table 2-7
Memory Installation Patterns (CMUU Added) in the SPARC M12-2/M12-2S (16 Memory Slots)
Memory Module Count Installed Memory
8a in Figure 2-5 ---
16 a in Figure 2-5 c in Figure 2-5 --
24 a in Figure 2-5 c in Figure 2-5 b in Figure 2-5 -
32 a in Figure 2-5 c in Figure 2-5 b in Figure 2-5 d in Figure 2-5
Table 2-8
Memory Installation Patterns (CMUU Added) in the SPARC M12-2/M12-2S (24 Memory Slots)
Memory Module
Count
Installed Memory
8a in Figure
2-6
-----
16 a in Figure
2-6
b in Figure
2-6
----
24 a in Figure
2-6
b in Figure
2-6
c in Figure
2-6
---
32 a in Figure
2-6
b in Figure
2-6
c in Figure
2-6
d in Figure
2-6
--
40 a in Figure
2-6
b in Figure
2-6
c in Figure
2-6
d in Figure
2-6
e in Figure
2-6
-
48 a in Figure
2-6
b in Figure
2-6
c in Figure
2-6
d in Figure
2-6
e in Figure
2-6
f in Figure
2-6
XSCF>
showhardconf
SPARC M12-2S;
+ Serial:PZ51649002; Operator_Panel_Switch:Service;
+ System_Power:On; System_Phase:Cabinet Power On;
Partition#0 PPAR_Status:Running;
BB#00 Status:Normal; Role:Master; Ver:3015h; Serial:PZ51649002;
+ FRU-Part-Number:CA20369-B17X 005AC/7341758 ;
+ Power_Supply_System: ;
+ Memory_Size:256 GB;
CMUL Status:Normal; Ver:2101h; Serial:PP164804GG ;
+ FRU-Part-Number:CA07855-D301 A5 /7341541 ;
+ Memory_Size:128 GB; Type: C ;
2.2.2 Checking Memory Information
Check the type and size of memory by using the showhardconf command of the
XSCF firmware.
1.
Log in to the XSCF shell.
2.
Execute the showhardconf command.
[Command execution example]
Chapter 2 Understanding the System Units 21
