Fujitsu Oracle SPARC M12-2 User Manual

Caution -
Before you handle any unit, be sure to wear a wrist strap to ground any
static electricity. If you perform this procedure without a wrist strap, individual
components or the overall system may be seriously damaged. For details, see "1.5
Precautions on Static Electricity."
Note -
When removing the XSCFU of the SPARC M12-2S in a building block configuration,
do not remove the power cord, XSCF DUAL control cable, or XSCF BB control cable.
Note that, when replacing the XSCFU with the server in the cold state, you cannot
replace the XSCFU and PSUBP at the same time. That would cause the system to
malfunction.
11.4 Removing the XSCFU
This section describes the procedure for removing the XSCFU.
1.
Remove the LAN cables, USB memory, and other components connected to
the XSCFU.
Remove the LAN cable, serial cable, and USB memory from the XSCFU.
Figure 11-2
Removing Cables and USB Memory
2.
Lower the cable support.
Loosen the screws securing the cable support,
and then pull out the cable
Chapter 11 Maintaining the XSCF Unit 375
