Table 2-1
Memory Module Combinations in the SPARC M12-2/M12-2S (16 Memory Slots)
Memory Group
AB
(a) 64 GB memory module
8 GB DIMM x 8-
8 GB DIMM x 8 8 GB DIMM x 8
(b) 128 GB memory module
16 GB DIMM x 8-
16 GB DIMM x 816 GB DIMM x 8
(c) 256 GB memory module
32 GB DIMM x 8-
32 GB DIMM x 832 GB DIMM x 8
(d) 512 GB memory module
64 GB DIMM x 8-
64 GB DIMM x 864 GB DIMM x 8
Mix of (a) and (b)
8 GB DIMM x 816 GB DIMM x 8
16 GB DIMM x 8 8 GB DIMM x 8
Mix of (a) and (c)
8 GB DIMM x 832 GB DIMM x 8
32 GB DIMM x 8 8 GB DIMM x 8
Mix of (b) and (c)
16 GB DIMM x 832 GB DIMM x 8
32 GB DIMM x 816 GB DIMM x 8
Mix of (c) and (d)
32 GB DIMM x 864 GB DIMM x 8
2.2.1 Memory Installation Rules
Install memory according to the following rules.
■
Install the memory in units of eight modules.
■
All of the memory installed in a unit of eight modules must be of the same
capacity, rank, and type.
■
Within the same system, you can install memory modules of different capacities.
However, the memory installed in the DIMM slots under each CMU (CMUL or
CMUU) must be a combination of memory modules shown in Table 2-1 and Table
2-2.
■
When installing memory modules for the CMU in the SPARC M12-2/M12-2S (16
memory slots), install memory group A and then memory group B.
■
When installing memory modules of different capacities for the CMU in the
SPARC M12-2/M12-2S (24 memory slots), install memory group A, memory group
B, and memory group C in this order, from largest to smallest capacity.
■
For the SPARC M12-2S in a multiple-BB configuration, install at least one set of
memory modules (eight dual inline memory modules (DIMMs)) in each chassis.
■
To mount a 64 GB DIMM, see "Notes on Memory" in the latest version of the
Fujitsu SPARC M12 Product Notes.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 202316
