Table 5-17
Inactive/Cold Addition Procedure of a PCI Expansion Unit
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Powering off the physical partition
containing the SPARC M12-2S requiring
maintenance
"9.5.1 Stopping a Specific Physical
Partition"
3 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
4 Releasing the SPARC
M12-2S requiring
maintenance from the building block
configuration, and removing the power
cords
"9.6.1 Releasing the SPARC M12-2S
From the Building Block Configuration"
"9.8.2 Removing the Power Cords"
5Removing the PCICS from the SPARC
M12-2S
"12.3.1 Enabling the Removal of a PCIe
Card"
6Removing the PCIe card filler from the
PCICS
"12.3.2 Removing a PCIe Card or PCIe
Card Filler"
7 Installing a link card in the PCICS to
install it in the SPARC M12-2S
"12.4.1 Installing a PCIe Card or PCIe
Card Filler"
8 Connecting a PCI expansion unit to the
link card
"5.2 Connecting Cables to the PCI
Expansion Unit" in
the Fujitsu SPARC
M12-2S Installation Guide
9 Installing a PCIe card in the PCI
expansion unit.
"12.4.1 Installing a PCIe Card or PCIe
Card Filler"
10 Installing the power cords on the SPARC
M12-2S with the added PCI expansion
unit, and incorporating it into the
building block configuration
"10.1.1 Installing a Power Cord
"
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
11 Diagnosing the SPARC M12-2S with the
added PCI expansion unit
"10.5.1 Diagnosing the SPARC M12
Hardware"
12 Confirming that there is no problem with
the added PCI expansion unit
"10.5.3 Checking the FRU Status After
Maintenance"
5.4.5 Inactive/Cold Addition Workflow of the PCI
Expansion Unit
You can perform inactive/cold addition of a PCI expansion unit in the following
configuration:
■
Building block configuration where two or more physical partitions are operating
Before adding the PCI expansion unit, mount it in the rack. (See "3.4 Mounting the
SPARC M12-2S and the PCI Expansion Unit in a Rack" in the Fujitsu SPARC M12-2S
Installation Guide.)
Table 5-17 shows the workflow for inactive/cold addition
of a PCI expansion unit.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023174
