Table 5-8
Active/Cold Addition Procedure of a PCI Expansion Unit (continued)
Work
Order
Task Reference
7 Releasing the SPARC M12-2S requiring
maintenance from the building block
configuration, and removing the power
cords
"9.6.1 Releasing the SPARC M12-2S
From the Building Block Configuration"
"9.8.2 Removing the Power Cords"
8Removing the PCICS from the SPARC
M12-2S
"12.3.1 Enabling the Removal of a PCIe
Card"
9Removing the PCIe card
filler from the
PCICS
"12.3.2 Removing a PCIe Card or PCIe
Card Filler"
10 Installing a link card in the PCICS to
install it in the SPARC M12-2S
"12.4.1 Installing a PCIe Card or PCIe
Card Filler"
11 Connecting a PCI expansion unit to the
link card
"5.2 Connecting Cables to the PCI
Expansion Unit" in the Fujitsu SPARC
M12-2S Installation Guide
12 Installing the power cords on the SPARC
M12-2S with the added PCI expansion
unit, and incorporating it into the
building block configuration (*1)
"10.1.1 Installing a Power Cord"
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
13 Diagnosing the SPARC M12-2S
with the
added PCI expansion unit
"10.5.1 Diagnosing the SPARC M12
Hardware"
14 Powering on the physical partition of the
added PCI expansion unit
"10.9.1 Starting the System With an
XSCF Command"
15 Confirming that there is no problem with
the added PCI expansion unit
"10.5.3 Checking the FRU Status After
Maintenance"
16 Incorporating the SPARC M12-2S with
the added PCI expansion unit into the
physical partition
"10.6.1 Incorporating the SPARC
M12-2S Into the Physical Partition Using
PPAR DR"
17 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
18 Assigning the I/O resource to a logical
domain
"3.2 Operations and Commands
Related
to Logical Domain Configurations" in the
Fujitsu SPARC M12 and Fujitsu
M10/SPARC M10 Domain Configuration
Guide
*1 Do not mount any PCIe card in the PCI expansion unit during active addition of the PCI expansion unit.
5.2.6 Active/Cold Addition Workflow of the SPARC
M12-2S
Before adding the SPARC M12-2S to the building block configuration, see
"Precautions for SPARC M12-2S addition" in "7.2 Precautions for FRU Expansion."
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023162
