Fujitsu Oracle SPARC M12-2 User Manual

Table 4-36
Inactive/Cold Replacement Procedure of the OPNL
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the OPNL to be replaced "8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2S that houses the OPNL to
be replaced
"2.4 Understanding the LED Indications"
4 Powering off the physical partition
containing the SPARC M12-2S that
houses the OPNL requiring maintenance
"9.5.1 Stopping a Specific Physical
Partition"
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
6 Releasing the SPARC M12-2S requiring
maintenance from the building block
configuration
"9.6.1 Releasing the SPARC M12-2S
From
the Building Block Configuration"
7Placing the SPARC M12-2S requiring
maintenance into the cold state, and
removing the OPNL from the SPARC
M12-2S
"16.3 Removing the HDDBPU or OPNL"
8 Installing the OPNL on the SPARC M12-2S,
and placing the SPARC M12-2S into the
hot state
"16.4 Installing the HDDBPU or OPNL"
9 Incorporating the SPARC M12-2S that
required maintenance into the building
block configuration
"10.4.1 Incorporating the SPARC
M12-2S Into a Building Block
Configuration"
10 Confirming that there is no problem with
the replacement OPNL
"10.5.3 Checking the
FRU Status After
Maintenance"
11 Switching the mode switch on the OPNL
to Locked, and powering on the physical
partition containing the SPARC M12-2S
that has undergone maintenance
"10.8 Powering on a Physical Partition"
12 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains
"
4.4.8 Inactive/Cold Replacement Workflow of the OPNL
You can perform inactive/cold replacement of the OPNL in the following configuration:
■
Building block configuration where two or more physical partitions are operating
Before replacing the OPNL, see "Precautions for OPNL replacement" in "7.1
Precautions for FRU Replacement."
Table 4-36 shows the workflow for inactive/cold replacement of the OPNL.
Chapter 4 FRU Replacement Workflows 113
