Table 5-13
Inactive/Cold Addition Procedure of a PCIe Card
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Powering off the physical partition
containing the SPARC M12-2S requiring
maintenance
"9.5.1 Stopping a Specific Physical
Partition"
3 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
4 Releasing the SPARC
M12-2S requiring
maintenance from the building block
configuration, and removing the power
cords
"9.6.1 Releasing the SPARC M12-2S
From the Building Block Configuration"
"9.8.2 Removing the Power Cords"
5Removing the PCICS from the SPARC
M12-2S
"12.3.1 Enabling the Removal of a PCIe
Card"
6Removing the PCIe card filler from the
PCICS
"12.3.2 Removing a PCIe Card or PCIe
Card Filler"
7 Installing a PCIe card in the PCICS to
install it in the SPARC M12-2S
"12.4.1 Installing a PCIe Card or PCIe
Card Filler"
the Fujitsu SPARC M12 Product Notes of the XCP version used.
Each of the following sections puts together the order of work and the tasks for each
FRU into a table. For details on each task, see the reference shown in the table.
The following FRUs are subject to inactive/cold addition:
■
PCIe card
■
HDD/SSD
■
CMUU
■
Memory
■
PCI expansion unit
■
SPARC M12-2S
5.4.1 Inactive/Cold Addition Workflow of a PCIe Card
You can perform inactive/cold addition of a PCIe card in the following configuration:
■
Building block configuration where two or more physical partitions are operating
Before adding a PCIe card, see "Precautions for PCIe card addition" in "7.2
Precautions for FRU Expansion."
Table 5-13 shows the workflow for inactive/cold addition of a PCIe card.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023168
