Table 4-64
System-Stopped/Cold Replacement Procedure of the Crossbar Cable (continued)
Work
Order
Task Reference
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
6Removing the power cords of all the
SPARC M12-2S units, and removing the
crossbar cable from the SPARC M12-2S
"19.3 Removing the Crossbar Cable"
7 Installing the crossbar cable on the
SPARC M12-2S, and installing the power
cords of
all the SPARC M12-2S units
"19.4 Installing the Crossbar Cable"
8 Diagnosing all the SPARC M12-2S units "10.5.1 Diagnosing the SPARC M12
Hardware"
9 Confirming that there is no problem with
the replacement crossbar cable
"10.5.3 Checking the FRU Status After
Maintenance"
10 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL
Control Function"
11 Powering on the physical partitions "10.9.1 Starting the System With an
XSCF Command"
12 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
Table 4-65
System-Stopped/Cold Replacement Procedure of the XBU
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the XBU to be replaced "8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2S that houses the XBU to be
replaced
"10.5.2 Diagnosing the XBU and
Crossbar Cable"
4 Stopping all physical
partitions "9.5.2 Stopping All Physical Partitions"
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
6Removing the power cords of all the
SPARC M12-2S units
"9.8.2 Removing the Power Cords"
4.6.14 System-Stopped/Cold Replacement Workflow of
the XBU
Table 4-65 shows the workflow for system-stopped/cold replacement of the XBU.
Chapter 4 FRU Replacement Workflows 145
