Table 4-52
System-Stopped/Cold Replacement Procedure of the XSCFU (continued)
Work
Order
Task Reference
10 Installing the power cords on all the
SPARC M12-2/M12-2S units
"10.1.1 Installing a Power Cord"
11 Diagnosing all the SPARC M12-2/M12-2S
units
"10.5.1 Diagnosing the SPARC M12
Hardware"
12 Confirming that there is no problem with
the replacement XSCFU
"10.5.3 Checking the FRU Status After
Maintenance"
13 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
14 Powering on the physical partitions "10.9.1 Starting the System With an
XSCF Command"
15 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
*1 Before replacing the XSCFU, confirm that the READY LED of the XSCFU is lit in green or off. If the READY
LED of the XSCFU is blinking, wait until the LED stays lit or is turned off.
- If the XSCFU requiring replacement is not running when the physical partition
containing the XSCFU is
powered on, perform active/hot replacement.
- If the physical partition containing the XSCFU requiring replacement is off, you can replace the XSCFU even
when it is not running. In that case, proceed to step 5.
*2 If the SD card installed in the maintenance part will be
used, this work is not required.
Table 4-53
System-Stopped/Cold Replacement Procedure of a PCIe Card
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Confirming the PCIe card to be replaced "8.2 Troubleshooting"
3 Checking the operation status of the
SPARC M12-2/M12-2S that houses the
PCIe card to be replaced
"Table 2-21 PCIe Card Slot LEDs and
Their
States"
4 Stopping all physical partitions "9.5.2 Stopping All Physical Partitions"
5 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
4.6.2 System-Stopped/Cold Replacement Workflow of a
PCIe Card
Before replacing the PCIe card, see "Precautions for PCIe card replacement" in "7.1
Precautions for FRU Replacement."
Table 4-53 shows the workflow for system-stopped/cold replacement of a PCIe card.
Chapter 4 FRU Replacement Workflows 133
