Fujitsu Oracle SPARC M12-2 User Manual

Table 5-17
Inactive/Cold Addition Procedure of a PCI Expansion Unit (continued)
Work
Order
Task Reference
13 Switching the mode switch on the OPNL
to Locked
"2.3.2 OPNL Control Function"
14 Powering on the physical partition of the
added PCI expansion unit
"10.9.1 Starting the System With an
XSCF Command"
15 Assigning the I/O resource to a logical
domain
"3.2 Operations and Commands Related
to Logical Domain Configurations" in the
Fujitsu SPARC M12 and Fujitsu
M10/SPARC M10 Domain Configuration
Guide
Table 5-18
Inactive/Cold Addition Procedure of the SPARC M12-2S
Work
Order
Task Reference
1 Checking the operating condition of the
system
"9.2.1 Checking the Operation Status of
Physical Partitions and Logical Domains"
2 Powering off the physical partition into
which to incorporate the added SPARC
M12-2S
"9.5.1 Stopping a Specific Physical
Partition"
3 Connecting the added SPARC M12-2S "3.4.1 Mounting the SPARC M12-2S in a
Rack" in the
Fujitsu SPARC M12-2S
Installation Guide
4 Switching the mode switch on the OPNL
to Service
"2.3.2 OPNL Control Function"
5 Incorporating the SPARC M12-2S into a
building block configuration (*1)
"10.3 Adding the SPARC M12-2S to a
Building Block Configuration"
6 Diagnosing the crossbar cable "10.5.2 Diagnosing the XBU and
Crossbar Cable"
5.4.6 Inactive/Cold Addition Workflow of the SPARC
M12-2S
You can perform inactive/cold addition of the SPARC M12-2S in the following model:
■
One or more SPARC M12-2S units
Before adding the SPARC M12-2S, see "Precautions for SPARC M12-2S addition" in
"7.2 Precautions for FRU Expansion." To mount the SPARC M12-2S to be added in a
rack, see "3.4.1 Mounting the SPARC M12-2S in a Rack" in the Fujitsu SPARC
M12-2S Installation
Guide.
Table 5-18 shows the workflow for inactive/cold addition of the SPARC M12-2S.
Chapter 5 FRU Addition Workflows 175
