Note -
When you have removed a PCIe card, this step is not necessary.
7.
Return the cable support to the original position.
Return the cable support to the original position, and then secure it with two
screws.
Figure 12-14
Securing the Cable Support
12.4.2 Incorporating a PCIe Card Into the System
This section provides an overview of the procedure for incorporating a PCIe card
into the system after PCIe card replacement or addition. For details, see "10.6
Incorporating the SPARC M12-2S or an I/O Device Into the PPAR" or "3.2
Operations and Commands Related to Logical Domain Configurations" in the Fujitsu
SPARC M12 and Fujitsu M10/SPARC M10 Domain Configuration Guide.
1.
Incorporate the PCIe card into the physical partition.
When incorporating the PCIe card in the active state, use PCI Hot Plug. For
details, see "10.6.2 Incorporating an I/O Device Into the Physical Partition by
Using the Hot Plug Function."
2.
Assign
the I/O resource to a logical domain.
Assign the I/O resource as appropriate for the I/O configuration of the logical
domain used. For details, see "10.7 Incorporating I/O Resources Into a Logical
Domain."
3.
Save the configuration information of the logical domain.
If there has been any change to the I/O resources
of the logical domain in such a
case as when you have added or removed a PCIe card or changed the mounting
location of a PCIe card, be sure to save the logical domain configuration
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023394
