Note -
If you are replacing only a FANU, this step is not necessary.
Note -
Make sure that the FANBPU has no FANUs in it when you insert it into the server.
14.4 Installing a FANU or the FANBPU
This section describes the procedure for installing a FANU or FANBPU.
14.4.1 Installing the FANBPU
Install the FANBPU when the server is in the cold state.
1.
Insert the FANBPU into the server.
Align the bottom left and right corners of the FANBPU with its slot inside the
server, and insert the FANBPU along the slot.
Figure 14-6
Installing the FANBPU
2.
Secure the FANBPU.
Tighten the three fixing
screws to secure the FANBPU.
Fujitsu SPARC M12-2/M12-2S Service Manual
･
January 2023408
